THERMOMAX® BOND 40

THERMOMAX® BOND 40 is a cement-based, polymer-modified board adhesive for external thermal insulation composite systems (ETICS). It is used to bond expanded polystyrene (EPS), extruded polystyrene (XPS) and mineral wool insulation boards to mineral substrates such as concrete, render, brick and aerated concrete.
It is a component of external thermal insulation composite systems (ETICS). System performance is assessed under EAD 040083-00-0404 (ETAG 004). Product performance has been determined in accordance with test methods EN 1542, EN 13494 and EN 1015-19.

Fields of Application
•    Bonding of insulation boards in external thermal insulation composite systems (ETICS)
•    Internal wall insulation applications
•    Basement and garage ceiling insulation applications
•    Bonding of EPS, XPS and mineral wool boards to mineral substrates

Advantages
•    Provides high bond strength to EPS, XPS and mineral wool boards
•    Elastic thanks to its polymer content; accommodates thermal movement
•    Highly permeable to water vapour; does not prevent the wall from breathing
•    Suitable for interior and exterior use
•    Easy to prepare and apply; does not slip
•    Resistant to freeze-thaw cycles


General Information

Material composition

Cement, mineral fillers and polymer additives

Appearance

Grey powder

Maximum aggregate size

Max. 0.8 mm

Density of the mix

~ 1.84 kg/dm³

Performance Data

Bond strength to substrate – concrete (EN 1542)

≥ 0.50 N/mm²

Bond strength to board – EPS (EN 13494)

≥ 0.08 N/mm²

(failure within the insulation board)

Bond strength to board – mineral wool (EN 13494)

≥ 0.015 N/mm²

(failure within the insulation board)

Water vapour diffusion resistance factor (EN 1015-19)

μ ≤ 25

Application Data

Mixing ratio

6.25 – 6.75 litres of water / 25 kg powder

(~ 0.25 – 0.27 litres of water / 1 kg powder)

Pot life

~ 2 hours

Open time

≥ 15 minutes

Waiting time before anchoring

Minimum 24 hours

Waiting time before base coat

Minimum 3 days

Application and substrate temperature

+5°C / +30°C

Service temperature

−20°C / +80°C

Consumption

4.5 – 6.0 kg/m²

(depending on the application method)

Safety Information

Reaction to fire class (EN 13501-1)

A2-s1,d0

Hazardous substances

Refer to SDS


The technical values stated were obtained at an ambient temperature of +23°C and 50% relative humidity. Higher temperatures shorten the stated times, lower temperatures extend them.
